Features:
• Zero clearance feature allows intallation for small space
• Conversion to propane gas is fast & easy-all provided with convertible gas valve/orifices for natural/propane gas.
• Easily applied in upflow or downflow installation with minimal conversion necessary.
• Installed is a 2-pipe(sealed combustion) using outdoor air
• Aluminized steel primary heat
exchanger.Secondary heat exchanger is corrosion resistant stainless steel materials
• Timed adjustable blower capability
for maximum comfort
• Airflow leakage less than 1% of nom airflow at duct blaster
• Quiet inducer operation
• 4 Speed Direct Drive PCS Blower
• Built-in, high level self diagnostics with fault code displays standard on integrated control module
• Self priming internal condensate trap for easy installation
• Inducer rotates for easy conversion of venting options
• Electronic hot ignition saves on fuel cost
|
Item |
Input-output
MBH |
Size-HxDxW |
Part # |
MG9 Furnace |
60-57 |
33˝x 16 3/8˝x 29 1/2" |
MG9S060B12MP |
MG9 Furnace |
80-76 |
33˝x 16 3/8˝x 29 1/2" |
MG9S080B12MP |
MG9 Furnace |
80-76 |
33˝x 19 7/8˝x 29 1/2" |
MG9S080B16MP |
MG9 Furnace |
100-95 |
33˝x 19 7/8˝x 29 1/2" |
MG9S100B16MP |
MG9 Furnace |
100-95 |
33˝x 19 7/8˝x 29 1/2" |
MG9S100B20MP |
|
